Description
ENGINE:
Four stroke, direct injection, water cooled diesel, comply w/ US TIER-4 final
norms
Type: Naturally aspirated direct injection diesel
Engine HP [kW] @ RPM: 38.7 [28.9] @ 2400
Displacement (in3): 167
Number of Cylinders: 4
Firing Order: 1-3-4-2
Bore & Stroke (in): 88.9 mm (3.5 in.) * 110 mm (4.33 in.)
Compression Ratio: 18.7:1
Low Idle RPM: 970-1030
High Idle RPM: 2570-2630
Injection Pump: BOSCH CB18-2L OHWCW
Accelerator : Hand lever & pedal
Muffler: Under hood muffler & downswept exhaust
Air Cleaner: Dry Type Air Cleaning System with Double Filter
Fuel: Ultra Low Sulfur Diesel
Fuel Tank gal (L): 7.7 (29)
POWER TAKE OFF:
Type: Independent
PTO Operation: Clockwise from rear of tractor
Rear PTO RPM: 540 @ 2376
Mid PTO RPM: 2000 (Opt.) @ 2526
PTO HP [kW]: 29.9 (22.3)
DASH INSTRUMENTS:
Tachometer & Hour Meter
Fuel Gauge
Temperature Gauge
Indicators for Warning Messages
4WD Drive Lamp
SAFETY EQUIPMENT:
Foldable ROPS w/ retractable Seat Belt
Safety Start Switches
Turn Signals/ Hazard Light
Mechanical Wet Disc Brakes
Electric Key Shut Off
Parking Brake Indicator on Dash
Water Temperature Gauge
DRIVE TRAIN:
Transmission: Synchromesh on Shuttle (Forward-Reverse Position) and main Gear
Shift of constant mesh
Number of Speeds: 8F/ 8R
Clutch: Dry-Single
Brakes: Wet Disc
HYDRAULICS:
Type: Open Center
Steering Pump Output gpm (L/min): 3.4 (12.8)
Implement Pump Output gpm (L/min): 7.7 (29)
Maximum Total Flow gpm (L/min): 11.4 (41.8)
3-Point Hitch: CAT I with Telescoping Stabilizers & Flex Links
Lift Capacity lb (kg): 2646 (1200)
Standard Rear Valve Fitment: 2205
OPERATOR STATION:
7 Pin socket [Optional]
Debris Shield
Wide Platforms Steps
Color Coded Controls
Toolbox
mComfort Seat w/ foldable armrests
FRONT AXLE:
Power Steering
Center Pivot, Reverse Eliot Type
Level Gears for Wider Steering
ELECTRICAL:
Battery: 12 V, 925 CCA
Alternator: 12 V, 90 A
Starter Capacity: 12 V, 2.2 kw with Solenoid Switch
Lights: Headlights, Tail Lights and Stop Lights
Gauges: Indicators for: Glow plug, Charge, Engine Oil Pressure
Switches: Safety start switches (Rnage lever, PTO lever, Clutch pedal)
Cold Temperature Starting Aid: Starter motor with pre-heater
Indicator Lights: 2 Rear signal lights
DIMENSIONS:
Paint: 110.4 (2804)
Overall Length in (mm): 127.8 (3246)
Overall Width in (mm): 62 (1574)
Overall Height in (mm): 91.5 (2324)
Wheelbase in (mm): 76.9 (1953)
Minimum Ground Clearance in (mm): 12.8 (325)
Weight lb (kg): 3186 (1448)
WHEELS & TIRES:
AG [Front/Rear]: 7 x 16 / 11.2 x 24
IND [Front/Rear]: 28 x 8.5-15 / 43 x 16-20
CAPACITIES:
Fuel Tank gal. (L): 7.7 (29.1)
Cooling System gal. (L): 1.4 (5.2)
Engine Oil gal. (L): 1.6 (6)
TRANS & DIFF gal. (L): 8.7 (32.9)
Front Axle & Final Drive Case gal. (L): 1.2 (4.5)
